Applications
Vacuum brazing is widely used for joining metallic materials (non-ferrous, stainless steel, aluminum, titanium, superalloy, cemented carbide) and metal-to-nonmetal joints such as copper-to-ceramic.
Features
Small deformation
High uniformity
Short vacuum recovery
Simple operation
Stable mechanical action
Auto fault alarm
High efficiency
Internal/external circulation cooling
Low use cost
Flexible programming
Manual / auto control
Model | Working dim. | Capacity | Max temp | Unifornity | Ultimate vac. | Press.rise | Gas press. |
HN-433 | 450×300×300 | 60 | 700-1200 | ±5 | 4.0E-1 / 6.7E-5 | 0.3-0.67 | ≥2 |
HN-644 | 600×400×400 | 200 | |||||
HN-755 | 700×500×500 | 300 | |||||
HN-966 | 900×600×600 | 500 | |||||
HN-1288 | 1200×800×800 | 1000 | |||||
HN-1811 | 1600×800×800 | 1500 | |||||
HN-2100 | 2000×800×800 | 1800 | |||||
HN-2599 | 2500×900×900 | 2200 | |||||
HN-3099 | 3000x900x900 | 2500 |
Non-standard models can be customized
