Applications
Mainly used for aero-engine blades, supercritical CO₂ systems, PCHE heat exchangers, missile fuzes in aviation, aerospace and shipbuilding; suitable for same/dissimilar metals and new materials.
Features
Integrated press & hot chamber
6-side multi-zone heating
Imported Mo/Ni-Cr heating strip
High-purity graphite elements
TZM alloy rams
Professional dynamic seal
3D FEA design
Ram flatness ≤0.05mm
Adaptive 360° rotation
Dual pressure/displacement control
HMI+PLC, remote diagnosis
Electric loading cart
Model | Hot zone(WxLxH) | Power(kW) | Max temp(℃） | Ton（T） | Uniformity（℃） | Vacuum（Pa） | Press. rise（Pa/h） |
HN-222 | 200x200x(200-400) | 10-100 | 600-2600 | 30-2000 | ±3 | 4×10⁻³/ 5×10⁻⁴ | ≥2 |
HN-443 | 400x400x(300-600) | 30-200 | |||||
HN-554 | 500x500x(400-800) | 30-300 | |||||
HN-664 | 600x600x(400-1000) | 50-400 | |||||
HN-774 | 700x700x(400-1200) | 50-500 | |||||
HN-885 | 800x800x(500-1500) | 100-800 | |||||
HN-996 | 900x900x(600-1500) | 200-1000 | |||||
HN-1010 | 1000x1000x(600-1800) | 200-1300 | |||||
HN-1212 | 1200x1200x(600-2000) | 300-1500 | |||||
HN-1313 | 1300x1300x(800-2000) | 300-2000 | |||||
HN-1414 | 1400x1400x(800-2000) | 300-2000 | |||||
HN-1616 | 1600x1600x(800-2000) | 300-2000 |
Non-standard models can be customized
