Applications
Mainly used for sintering metal powder, MIM products, ceramics, cemented carbide, stainless steel fibers; temperature customized per requirements
Features
Stainless steel frame, carbon felt
Small deformation, easy maintenance
Graphite tube heating, low failure
All-metal shield, Mo elements
Evenly arranged elements
PLC, auto/semi-auto/manual
Model | Working dim.(mm) | Capacity(kg) | Power(kW) | Max temp(℃） | Unif.（℃） | Ultimate vac.（Pa） | Gas（bar） | Pressure≤150 | Rise（Pa/h） |
HN-433 | 400x 300x 300 | 100 | 55 | 2500 | ±5 | 4.0E-1/ 6.7E-3 | ≥2 | ≤150 | 0.67 |
HN-644 | 600x 400x 400 | 200 | 80 | ||||||
HN-755 | 700x 500x 500 | 300 | 100 | ||||||
HN-966 | 900x 600x 600 | 500 | 150 | ||||||
HN-1288 | 1200x 800x 800 | 1000 | 240 |
Non-standard models can be customized
